Optics, Physics
Planck’s Constant
Catalogue No: 1110845
Seven LED’s of different wavelengths mounted on a moulded plastic case (142x80x40) mm approx, selectable through a rotary switch. The apparatus uses a 5V DC input external 4mm sockets. To monitor the current and voltage across each LED additional 4mm sockets are provided to connect voltmeter and ammeter. The operating voltage for the LED’s can be adjusted with the help of potentiometer.
* Planck’s ConstantPack of (Pcs): 1
SKU: 1110845 -
Optics, Physics
Planck’s Constant Apparatus
Catalogue No: 1110855/2
Uses SB- CS photoconductive cell, which works on UV – visible light spectrum range. Planck’s constant can be completed by finding the reverse potential applied to make photo cell current zero. A aperture provided for light of different colors (wave long the) incident on photo cell. BNC socket provided for connecting to Picometer. Picometer (Cat. no. 1091926) available separately.
* Set of 9 color filters specially used with the Planck’s Constant Apparatus (1110850/1)
Colour Wave Length
Green 510 x 560 nm
Orange 570 x 620 nm
Deep Blue 430 x 480 nm
Violet 380 x 450 nm
Red 620 x 670 nm
Blue 440 x 490 nm
Blue Green 470 x 520 nm
Yellow Green 530 x 570 nm
Orange 575 x 610 nmPack of (Pcs): 1
SKU: 1110855/2 -
Optics, Physics
Planck’s Constant Apparatus
Catalogue No: 1110855/1
Uses SB- CS photoconductive cell, which works on UV – visible light spectrum range. Planck’s constant can be completed by finding the reverse potential applied to make photo cell current zero. A aperture provided for light of different colors (wave long the) incident on photo cell. BNC socket provided for connecting to Picometer. Picometer (Cat. no. 1091926) available separately.
* Planck’s Constant ApparatusPack of (Pcs): 1
SKU: 1110855/1 -
Optics, Physics
Planck’s Constant Apparatus
Catalogue No: 1110851
A simple portable device for determination of planck’s constant. On providing input of 5V DC, the voltage across the three LEDs, can be varied through a knob and can be measured across a pair of 4mm sockets. The voltage at which a particular LED glows helps in computing the planck’s constant. Complete assembly mounted in plastic case, with circuit printed on it. Provision for external LEDs with fixed as well as variable voltage. Complete with user instruction manual.
* Plank’s Constant ApparatusPack of (Pcs): 1
SKU: 1110851
